The AMBIENCE loudspeakers feature a unique design with a high quality finishing and a superior sound performance. AMBIENCE is the ideal system to provide an exquisite and powerful sound to a wide range of movable and fixed installation applications such as on fashion shops or retail stores, luxurious KTVs, high-end bars and clubs, auditoriums, theaters or even home cinemas.


The AMBIENCE loudspeaker series includes four models, the COL4.3, COL8.3 and COL16.3 columns and the SUB210S subwoofer.
All AMBIENCE loudspeaker cabinets are made of MDF wood to improve its sound performance. MDF cabinets are very common on high fidelity loudspeakers as it helps to improve its rigidity and avoid undesired vibrations. On professional audio instead it’s not so common due to its increased weight.


The COL4.3, COL8.3 and COL16.3 columns are composed of four, eight and sixteen 3” full range neodymium drivers respectively. One of the major benefits of the COL speakers is the narrow vertical angle of its sound beam. This feature is very helpful to reduce undesired ceiling reflections and have a better distribution of the sound pressure. Additionally, on the COL8.3 and COL16.3, different vertical aperture angles of the sound beam can be selected by means of a slide switch (10°-20° for the COL8.3 and 15°-25° for the COL16.3), allowing to precisely focus the sound on the audience. For the COL4.3 the vertical aperture angle is fixed to 20°.
The COL speakers provide a crystal clear and free of distortion mid and high frequencies, particularly appropriate for vocals sound reproduction.


The SUB210S is composed of two 10” drivers and comes in a small cabinet form factor. It features a symmetrical position of the drivers and reflex ports placed on the bottom side of the cabinet. This innovative design cancels any cabinet vibration and distortion, translating to an exceptionally clean, deep, natural and punchy bass.


Curves of COL4.3、 COL8.3、 SUB210S:



The flexible installation method of the column can be adapted to various occasions, then you can enjoy the best sound in any environment.



Model COL4.3 COL8.3 COL16.3 COL24.3 SUB210S
Power Capacity 120W AES /240W Program /480W Peak 240W AES /480W Program /960W Peak 480W AES /960W Program /1920W Peak 720W AES /1440W Program /2280W Peak 800W AES /1600W Program /3200W Peak
Nominal Impedance
Frequency Response (-6dB) 170Hz-13.5kHz 10° setting:180Hz-16kHz
20° setting:180Hz-13kHz
15° setting:180Hz-13kHz      30° setting:180Hz-14kHz 15° setting:135Hz-13kHz (-6dB)
30° setting:185Hz-12.5kHz (-6dB)
Sensitivity 99dB 1W/1m 101dB 1W/1m 104dB 1W/1m 103dB 1W/1m 96dB 1W/1m
Maximum SPL 120dB Continuous, 123dB Program, 126dB Peak 125dB Continuous, 128dB Program, 131dB Peak 131dB Continuous, 134dB Program, 137dB Peak 131dB Continuous, 134dB Program, 137dB Peak 125dB Continuous, 128dB Program, 131dB Peak
Horizontal 120°±30° 800Hz-5kHz ,
60°±10° 6kHz-16kHz
120°±30° 800Hz-5kHz ,
50°±15° 6kHz-16kHz
120°  ±30°  600Hz-9kHz ,
50°  ±15°  6kHz-13kHz
120°  ±30°  600Hz-9kHz ,
50°  ±15°  6kHz-13kHz
Vertical 20°±5° 2.5kHz-8kHz, 40°±25° 1kHz-13.5kHz 10° setting: 10° ±5° 2kHz-16kHz
20° setting: 20° ±5° 1.3kHz-16kHz
120°±30° 800Hz-5kHz , 50°±15° 6kHz-16kHz 15° setting: 15° ±5° 600Hz-9kHz , 30° setting: 30° ±5° 400Hz-14kHz
Driver 4 x 3″ Full Range European Neodymium driver” 8 x 3″ Full Range European Neodymium driver” 16 x 3″ Full Range European Neodymium driver 24 x 3″ Full Range European Neodymium driver 2 x 10″ Full Range European Ferrite driver
Voice coil 0.75″ 0.75″ 0.75″ 0.75″ 2.5″
Connector 1x Euroblock (Phoenix connector) 42A rated with locking screws
Cabinet CNC made 12mm MDF, smooth non glossy white painting
Hanging side frame Flying:2 M6 insertion points on top and rear for eye bolts
Wall:4 M5 insertion points on rear face for swivel-tilting wall/pole bracket,2 M6 insertion points on top and bottom for “U” bracket
Pole:2 M4 insertion points on bottom face for pole adaptor
M20 threaded insert on top for pole assembly
Product Dimensions(mm) 114 x 400 x 119 114 x 720 x 119 114 x 1400 x 119 114 x 2060 x 119 450 x 550 x 450
Package Dimensions(mm) 160 x 500 x 170 160 x 810 x 170 160 x 1490 x 170 200 x 2150 x 210 660 x 590 x 560
N.W 3kg 5.2kg 10.4kg 15.5kg 36kg
G.W 3.8kg 6.3kg 12.2kg 41kg


COL4.3 COL8.3 COL16.3
