SUB136T/SUB136/SUB136W

The SUB136T/SUB136/SUB136W is a Dual 18-inch ultra low frequency line array loudspeaker that can be used with IWAC220 suspension or stacking.
The AES standard power can withstand 4800W/4Ω with a highest sound pressure continuous output up to 140dB.(Peak level at 1 m under half space)
Uniquely symmetrical design, with front and rear speakon terminals, can physically meet the symmetrical placement of CSA.
Birch plywood cabinet with CNC manufacturing process,emery spraying craft make it highly durable which make it can be able use in small and medium tour show and need medium throw distance application.


Specifications

Model SUB136T SUB136/SUB136W
Frequency Range 28~1.4kHz(-10dB) 28~1.4kHz(-10dB)
Frequency Response 35~100Hz(-6dB) 35~100Hz(-6dB)
Sensitivity 100dB(1W/m) 100dB(1W/m)
Maximum SPL >140dB(Peak level at 1 m under half space) >140dB(Peak level at 1 m under half space)
Power Handling 2400W(AES) 2400W(AES)
Program Power 4800W 4800W
Nominal impedance
LF Drivers 2×18″Carbon fiber cone ferrite driver 2×18″Carbon fiber cone ferrite driver
Voice coil 4”(100mm) 4”(100mm)
N.W 91kg(SUB136T) / 122kg(SUB136T-PCWBKS) 89kg
Product Dimensions(mm) W1060xH500xD950mm (SUB136T)
W1110xH1150xD560mm (SUB136T-PCWBKS)
W1060xH500xD950mm
Connection 1xNEUTRIK® NL4 SPEAKON INPUT : ±1 1xNEUTRIK® NL4 SPEAKON INPUT : ±1

Dimensions

SUB136TSUB136T SUB136/SUB136WSUB136/SUB136W
